Technical Specifications

Glazed
Porcelain Tiles

TECHNICAL SPECIFICATIONS
CHARACTERISTICS TEST METHOD INTERNATIONAL STD
ISO 13006/EN 176 (GROUP Bla)		 PORTOCER VALUE
DIMENSION & SURFACE QUALITY
Deviation in Length ISO-10545-2 ±0.6% ±0.2%
Deviation in Thickness ISO-10545-2 ±5% ±4%
Straightness of Sides ISO-10545-2 ±0.5% ±0.2%
Rectangularity ISO-10545-2 ±0.6% ±0.2%
Surface Flatness ISO-10545-2 ±0.5% ±0.2%
PHYSICAL & THERMAL PROPERTIES
Water Absorption ISO-10545-3 <0.5% <0.2%
Breaking Strength ISO-10545-11 >1300 N >1800 N
Flexural Strength (Modulus of Rupture) ISO-10545-4 >35 N/mm2 >38 N/mm2
Mohs Hardness EN-101 Depends on the product As Per Surface Finish
Resistance to Surface Abrasion ISO-10545-7 Depends on the product As Per Surface Finish
Skid Resistance (Friction Coefficient) ISO-10545-17 Depends on the product As Per Surface Finish
Frost Resistance ISO-10545-12 Frost Proof Frost Proof
Thermal Shock Resistance ISO-10545-9 No Damage No Damage
Moisture Expansion ISO-10545-10 NIL NIL
CHEMICAL PROPERTIES
Resistance to Acid and Alkalies ISO-10545-13 No Damage No Damage
Resistance to household chemicals ISO-10545-16 No Damage Minimum GB
Color Resistance ISO-10545-16 No Damage No Damage
Stain Resistance ISO-10545-14 Resistant Resistant

GLAZED PORCELAIN TILES (GROUP-Bla)
DIMENSION PROPERTIES
AS PER INTERNATIONAL STANDARDS
  • ISO 13006:2018 0,
  • EN 14411 (EUROPEAN STANDARDS)
  • TIS 2508-2555 (THAILAND STANDARDS)
  • ANSI A137.1:2022 (AMERICAN NATIONAL STANDARDS)
PHYSICAL PROPERTIES :
  • WATER ABSORPTION : < 0.1%
  • BREAKING STRENGTH : > 1800 N
  • MODULUS OF RUPTURE : > 42 N/MM2
THERMAL AND CHEMICAL PROPERTIES :
  • FROST RESISTIVE
  • THERMAL SHOCK RESISTIVE
  • FIRE RESISTIVE
  • ACIDS RESISTIVE
  • ALKALIES RESISTIVE
  • STAINS RESISTIVE
  • HOUSEHOLD CHEMICALS RESISTIVE
